Smart Car Park Solution
The key factors that set smartcard car park system apart from others is the latest technological advanced car park system that the world is now recognizing. Throughout the world, car park operators are switching from the traditional magnetic stripe and bar-coded tickets to a recycleable Smartcard ticketing. Smartcard offers better security, system scalability with wider application of choice and the cost savings in printed tickets.A more modern system users a Smartcard based automatic pay stations, where the driver presents the smartcard ticket and pays the fee required before returning to their car, then drives to the exit station and insert the paid ticket for exit.
The latest technology Smartcard Autopay Station offers you an innovative ticket handling system for the parking operation. This robust self-service station is designed to improve cash management ,lower labor and operational expenses while improving customer service and convenience round the clock, 24 hour operation. The ergonomic design and user-friendly Smartcard Autopay Station guides customers through the entire transaction process with ease . Clearly defined instructions in Bahasa Malaysia and English are simple to follow without the confusion. These pay station accepts payment banknotes and provide change in banknotes (Coins option available).
Key components
- Entry Station
- Exit Station
- Manual Pay Station
- Autopay Station (APS)
- Car Park Barrier
- Car Park Management Centre Server (CPMC)
- Parking Application Software & Reports
- Intercom
- Ticket Redemption & Validation Handheld Reader
- Parking Tickets (Ticketing & Season)
- Touch ‘n Go System
- Smartcard Comparison (Advantages)
- Reference Sites
The MIFARE name covers proprietary technologies based upon various levels of the ISO / IEC 14443 Type A 13.56 MHz contactless smartcard standard
1. Entry Station
The Entry Station is designed to provide all the features that maybe needed for control at the entrance. It accommodates the following devices:
- Ticket Dispenser: Issue Smartcard Ticket with the data & time, lane #, ticket # etc. This ticket can be issued automatically or as soon as the flashing “Button” is pressed.
- Card Reader: As a read/write device for registering a valid parking ticket.
- Back-lit LED Display: A large character LED display provides user instructions, messages, date & time .
- Alarm for low ticket , reminder to replenish tickets
- Intercom: Aiphone hardwired Intercom unit that is connected to a master station located at the Car Park Management Centre
- Interlocking: Ticket/Season Card interlock: This assures that the parker can only use one of the access modes available to him. So a card user cannot take a ticket and so on. Anti-passback function enabled.
- TCP/IP Controller: The heart of the system is this high-power controller that monitors all the activity in the lane and provides the interaction to the Car Park Management Centre Server via a LAN/WAN interconnection that is standard in most locations
